Hydraulic eagle shears are hydraulic attachments for excavators. They get their name because their jaws look like an eagle’s beak. They are also known as scrap‑steel shears or car‑dismantling heavy‑duty shears. Driven by an excavator’s hydraulic system, they are mainly used for heavy‑duty metal shearing and dismantling work. They are widely used in end‑of‑life vehicle dismantling, scrap‑steel recycling, steel‑structure demolition and ship‑breaking operations.
YG Machinery offers nine models of hydraulic eagle shears for sale, from the YG180RT (fits 13-17 ton excavators) up to the YG980RT (fits 91-110 ton excavators). Opening widths range from 375mm to 950mm. Cutting depths range from 395mm to 940mm. Weight from 1100kg to 9800kg. All models feature 360° rotation, reversible blades, and bolt-on wear parts. This article helps you pick the right hydraulic eagle shear for your excavator and shows you why it beats a torch every time.
Hydraulic Eagle Shear For Sale – 9 Models, One Match for Excavator
The first thing every buyer asks: “Will this shear work on my excavator?” YG makes nine sizes, covering machines from about 10 tons up to 110 tons. Focus on two things: your excavator’s weight and the size of steel you cut most often.
| Item/Model | Unit | YG180RT | YG280RT | YG330RT | YG380RT | YG430RT | YG480RT | YG580RT | YG780RT | YG980RT |
| Arm Installation | ton | 13–17 | 18–27 | 25–35 | 28–39 | 40–50 | 42–50 | 51–65 | 68–90 | 91–110 |
| Boom Installation | ton | 10–12 | 14–18 | 20–28 | 20–28 | 28–39 | 28–39 | 40–50 | 51–65 | 66–90 |
| Working Pressure | bar | 250–300 | 250–300 | 300–320 | 320–350 | 320–350 | 320–350 | 320–350 | 320–350 | 320–350 |
| Working Flow | lpm | 90–110 | 180–220 | 200–250 | 200–250 | 250–300 | 250–300 | 275–375 | 500–600 | 600–700 |
| Weight | kg | 1100 | 2100 | 3000 | 3500 | 4500 | 4600 | 5800 | 7800 | 9800 |
| Rotating Flow | lpm | 30–40 | 30–40 | 30–40 | 30–40 | 30–40 | 30–40 | 30–40 | 50–60 | 55–65 |
| Rotating Pressure | bar | 90–100 | 100–115 | 100–115 | 100–115 | 100–115 | 100–115 | 100–115 | 140–150 | 170–190 |
| Opening | mm | 375 | 485 | 595 | 620 | 700 | 740 | 780 | 860 | 950 |
| Cutting Depth | mm | 395 | 525 | 630 | 600 | 720 | 750 | 780 | 850 | 940 |
| Length | mm | 2100 | 2700 | 3200 | 3280 | 3700 | 3800 | 4000 | 4300 | 4600 |
What Can You Cut With an Excavator Scrap Shear?
A hydraulic eagle shear is built for one job: cutting steel fast. Here’s what it handles best:
- Rebar and reinforcing steel – Up to 30- 40 mm thick, depending on the model.
- Steel beams – I-beams, H-beams, channel steel. The YG980RT with 950mm opening bites through beams over 300mm tall.
- Steel pipes and tubes – Round or square.
- Scrap cars – After removing the engine and fuel tank, a shear chops a car into pieces for the shredder.
- Light structural steel – Mezzanines, guardrails, storage racks.
- Concrete with rebar – The shear cuts the steel, but you still need a crusher for the concrete.
What it’s NOT for: Hardened steel (springs, axles – those need a different tool). Stainless steel over 10mm thick. Cast iron. For those jobs, ask YG about hydraulic crushers or pulverizers.
The key is matching the shear’s opening and cutting depth to your typical scrap. If you mostly cut rebar and thin pipes, a YG280RT is plenty. If you’re demolishing steel-frame buildings, go for YG580RT or larger.
Why does a Hydraulic Eagle Shear Beat a Torch?
1. Speed. A hydraulic eagle shear closes and cuts in 2-4 seconds per cycle. A torch needs setup time, gas, a safety watch, and it leaves slag to clean up. The shear is grab, snip, drop, repeat.
2. Safety. The operator stays in the cab. No hot sparks, no oxygen bottles, no fire risk. The shears’ hoses have burst protection valves – if a hose blows, the jaws lock instead of dropping.
3. Cleaner scrap. Torch-cut edges have slag and oxidation, so recyclers pay less. Shear-cut edges are clean – higher resale value per ton.
4. 360° rotation. All YG models spin continuously. You don’t have to reposition the excavator to line up with an awkward beam. Just rotate the shear.
5. Low maintenance. Blades are reversible with four edges each. When one edge dulls, flip it. No welding, no special tools. A set of spare blades costs a fraction of a new shear.
Real-world example from our client: One contractor told us, “With a torch, two guys processed 10 tons of scrap in a shift. With the YG shear, one guy processes 25 tons.” That’s the real difference.
How to Choose the Right Hydraulic Eagle Shear For Sale – 4 Simple Questions
1. What size is my excavator? Check the “arm installation” weight column. A 25-ton excavator fits the YG330RT (25-35 tons) or YG380RT (28-39 tons).
2. What’s the thickest steel I need to cut? Bigger opening and cutting depth mean thicker material. The YG280RT cuts 525mm deep – plenty for most scrap. The YG980RT cuts 940mm deep – for heavy demolition.
3. Do I need 360° rotation? Yes. All YG models have it. It’s essential for working in tight spaces.
4. What’s my hydraulic flow? Check your excavator’s specs and compare them to the “working flow” column. If your flow is too low, the shear will move slowly. If it’s too high, you need a flow control valve.
Conclusion – Cut Faster and Safer with YG
Hydraulic eagle shear for sale from YG does the job faster, safer, and cleaner. YG offers nine models of excavators from 10 to 110 tons. Opening widths up to 950mm. Cutting depths up to 940mm. All with 360° rotation and reversible blades. Whether you’re processing scrap cars, demolishing steel buildings, or cutting rebar, there’s a YG shear that fits your machine.
YG Machinery also offers hydraulic crushers, pulverizers, grapples, and other demolition attachments. Contact YG with your excavator make, model, and typical scrap. They’ll recommend the right hydraulic eagle shear and provide a quote within 24 hours.
