YG Machinery recently delivered a high-performance laser screed to a leading engineering firm in France—a market where demand for advanced floor finishing equipment is steadily rising. In France, commercial construction projects such as shopping centers, office complexes, and underground parking facilities require flooring that combines exceptional flatness with aesthetic perfection. Traditionally, achieving such precision across both large open areas and narrow corners has been challenging, often requiring multiple machines or labor-intensive manual adjustments. As French construction standards continue to prioritize low-noise, zero-emission indoor operations, the need for automated, laser-guided solutions has grown significantly. Our client’s successful project demonstrates how the right equipment can transform efficiency and quality, and we are excited to share this story with contractors and developers seeking a reliable partner for their flooring needs.
Concrete Floor Leveling Machine Technical Parameter
| Model | YGJX31 | YGJX32 | YGJX33 | YGJX34 |
| Engine | ||||
| Model | Generator set | GX390 Electric start | GX390 Electric start | GX390 Electric start |
| Power | 2.0kW | 13hp/3600rpm | 13hp/3600rpm | 13hp/3600rpm |
| Fuel tank (L) | 14.5 | 6.5 | 6.5 | 6.5 |
| Running device | ||||
| Drive | Motor | Hydraulic motor | Hydraulic motor | Hydraulic motor |
| Running mode | Infinitely variable speed | Handle control, stepless speed | Handle control, stepless speed | Handle control, stepless speed |
| Running speed(m/min) | 0-36 | 0-45 | 0-65 | 0-45 |
| Suggest working speed(m/min) | 5 | 5 | 5 | 5 |
| Screed head | ||||
| Type | Self-leveling | Electric control, self-leveling | Self-leveling | Hydraulic control, self-leveling |
| Width | 2500mm | 2500mm | 2500mm | 2500mm |
| Exciting force | 500N | 500N | 500N | 500N |
| Vibration frequency | 50Hz | 50Hz | 50Hz | 50Hz |
| Laser control system | ||||
| Control type | Microcomputer laser scan | Microcomputer laser scan | Microcomputer laser scan | Microcomputer control |
| Operation mode | Walk-behind | Walk-behind | Walk-behind | Walk-behind |
| Forward and reverse | Handgrip control, stepless speed-walking | Hydraulic control | Handgrip control, stepless speed-walking | Hydraulic control |
| Size and weight | ||||
| Working size(mm) | 2758*2622*1980 | 2740×2659×1980 | 2578×2643×1980 | 2780*2622*1980 |
| Weight(kg) | 295 | 365 | 380 | 410 |


Detailed information about the sale of laser leveling machines
A French engineering company contracted to handle floor construction for a large commercial complex—comprising a shopping mall, office buildings, and an underground parking structure—faced a demanding set of requirements. The site featured both expansive open areas and narrow corners, making it difficult for conventional equipment to handle both effectively. Indoor work conditions required low noise and zero emissions, and the finished floor needed exceptional flatness to support tile and epoxy coating with no room for imperfections.
Initially, the team used an automatic planer for the large open sections. However, they still needed a solution capable of delivering the same precision in corners and edges. After evaluating several options, they selected YG’s walk-behind concrete laser screed. This machine was deployed specifically for the intricate areas, working seamlessly alongside their existing equipment.
The electric drive system allowed the machine to operate at noise levels below 55 decibels—well within indoor construction limits. The imported laser guidance system ensured that every section met strict flatness standards. Auxiliary tools included with the machine also facilitated secondary surface finishing, significantly enhancing the final aesthetic quality.
The results spoke for themselves. The construction team completed 15,000 square meters of flooring in just six days—a 50% increase in efficiency compared to traditional methods. Floor flatness was maintained within ±1.5 mm over three meters, meeting the rigorous requirements for subsequent tile and epoxy installation. The low-noise operation received full approval from local regulators, and the equipment ran continuously for a month without any malfunction, demonstrating exceptional durability. The project passed final inspection with no issues.
The client later shared their feedback, noting how the laser screed integrated seamlessly with their automatic planer. They highlighted that the machine delivered the precision and efficiency required for their high-quality standards while meeting environmental requirements for indoor construction. With its outstanding performance and value, they expressed interest in a long-term partnership with YG.


Why the French Client Chose YG Machinery
The client’s decision was driven by the machine’s ability to address their specific project challenges. The combination of automated operation, laser-guided accuracy, and electric drive offered a complete solution that traditional equipment could not provide. YG’s commitment to durable, high-performance machinery gave the client confidence that their investment would support project requirements without downtime or compliance concerns.
YG Machinery is committed to providing reliable equipment that meets the evolving needs of construction professionals worldwide. Whether your project demands precision on a large scale or accuracy in confined spaces, a laser screed can help you achieve superior results with greater efficiency.
