A paper egg tray making machine, also known as pulp molding equipment, is a specialized industrial system. Pulp molding equipment uses waste book paper, waste newspapers, waste cartons, waste scraps from printing and packaging plants, and tailings from paper mills as raw materials to produce and process various degradable egg trays, egg boxes, shoe linings, and paper trays for electronic product inner packaging. The production steps are beating, molding, dehydration, drying, and packaging.
Because the machine uses recycled paper as its primary raw material and the finished products are fully biodegradable, it plays a vital role in sustainable packaging solutions worldwide. Whether for a poultry farm or a dedicated packaging factory, investing in a reliable paper egg tray-making machine helps reduce plastic waste while creating a new revenue stream from discarded paper.
Main Technical Parameters Of Paper Egg Tray Making Machine
| Model | Capacity/H | Power/hour | Paper Consumption/H | Water Consumption/H | Dry System | Weight | Dimensions (main machine) |
| YG-1500 – 4X1 | 1500pcs/h | 38kw | 120kg | 240kg | dry naturally | 3000kg | 2800*2200*1900 |
| YG-2500 – 3X4 | 2500pc/h | 55kw | 200kg | 400kg | multi-layer drying | 4000kg | 2900*1800*1800 |
| YG-3000 – 4X4 | 3000pcs/h | 60kw | 240kg | 480kg | multi-layer drying | 4800kg | 3250*1800*1800 |
| YG-4000 – 4X8 | 4000pcs/h | 95kw | 320kg | 640kg | multi-layer drying | 7000kg | 3250*2300*2500 |
| YG-5000 -5X8 | 5000pcs/h | 95kw | 400kg | 800kg | multi-layer drying | 8000kg | 3300*2300*2500 |
| YG-7000 -6X8 | 7000pcs/h | 120kw | 480kg | 960kg | multi-layer drying | 10000kg | 3400*2300*2500 |
How Does The Paper Egg Tray Making Machine Work?
The working principle of the paper egg tray making machine is simple and efficient, consisting of 5 key steps that ensure stable and high-quality production. First, pulping: Put waste paper into the pulper, add an appropriate amount of water, and stir to form a fiber suspension. Second, pulp delivery: The water pump transports the prepared pulp to the machine’s water storage tank for standby. Third, molding: The vacuum system adsorbs the pulp onto the molding mold, and excess water is recycled back to the storage tank for reuse. Fourth, pressing and demolding: The air compressor provides compressed air to combine the molding mold and transfer mold, pressing the pulp into the shape of an egg tray, then demolding quickly. Fifth, drying: The formed wet egg trays are sent to the drying system to remove moisture, and the finished egg trays are ready for use after drying.
Outstanding Features Of Pulp Egg Tray Machine
- Fully Automatic Intelligent Production: Utilizing a PLC + touchscreen automatic control system, it achieves full automation of the entire process, including pulp preparation, pulp suction molding, transfer and demolding, drying and curing, and finished product conveying. No manual intervention is required, significantly reducing labor intensity and saving over 60% in labor costs compared to semi-automatic equipment.
- Environmentally Friendly and Energy-Saving Design: Using renewable resources such as waste paper and old cardboard boxes as raw materials, the production process has no wastewater or exhaust gas emissions, meeting green environmental protection requirements. The equipment uses energy-saving motors and high-efficiency heating elements, resulting in low energy consumption and significantly reducing operating costs over the long term.
- Easy Maintenance Design: Key components are arranged reasonably and disassemble easily. Wearable parts such as molds and filters are highly interchangeable and easy to replace. The equipment is equipped with a fault diagnosis system that can monitor the operating status of each component in real time and automatically alarm in case of failure, reducing maintenance difficulty.
Reliable Supplier Of Paper Egg Tray Equipment
Investing in a paper egg tray-making machine is more than buying equipment; it’s a strategic move toward operational independence, cost control, and environmental responsibility. From small farms to large-scale distributors, the ability to create your own high-quality, custom packaging from waste is a powerful competitive edge.
At YG Machinery, we specialize in guiding businesses through this transition. We offer a full range of solutions, from semi-automatic to fully automatic egg tray production lines, complete with custom mold design, comprehensive training, and reliable after-sales support. Beyond egg trays, our pulp molding machines can also produce fruit trays and industrial packaging, among other packaging products. Ready to explore your potential savings and ROI? Contact YG Machinery today for a free consultation and a detailed quote tailored to your production goals.
We have successfully exported paper egg tray forming machines to Ghana. For your reference: Our Ghanaian customer purchased our YG-2500 paper egg tray forming machine, which reduced production costs by 50% compared to imports and eliminated inventory shortages, successfully solving the problems of high costs and unstable supply of imported egg trays.
Frequently Asked Questions about YG Egg Tray Machines
A: High-quality machines are designed to process a wide variety of waste paper, including old newspapers, corrugated cardboard, office paper, and even agricultural residues like sugarcane bagasse. The versatility of the raw material input is a key factor in determining your long-term operational costs.
A: Proactive maintenance is key. Ask for a specific list of high-wear components (e.g., molds, vacuum filters, certain seals, and forming meshes) and their estimated working life under normal conditions. Ensure the supplier maintains a stock of these parts and has a straightforward process for international ordering and shipping. This directly impacts your long-term operational uptime and cost predictability.
A: If you have ample space and sufficient sunlight, natural drying can significantly reduce the initial investment of the egg tray making machine; if you pursue high efficiency and space utilization, a fully automatic metal drying line is a better option.
